Genuine Bosch 0580464200 Supersedes -044 - 200LPH Inline Fuel Pump Replaces 058025044

This is Bosch's new high performance fuel pump that replaces the classic Bosch -044 fuel pump!

This is a 100% Genuine Bosch Motorsports 0580464200 (a direct fit replacement for the superseded -044, 0580254044 or Bosch 61944 pump), as used by American, Japanese, European + Australian performance/ tuner shops, JGTC cars, touring cars, almost all WRC cars, and many more. This fuel pump flows about 15% more and weighs about 15% less than the old -044 pump. This fuel pump is also made to handle Ethanol (E85) better unlike the old -044 pump. Capable of providing 300LPH free flow and 200LPH at 5 bar (72.5 psi) for up to 685HP. In comparison, the Walbro GSS341 255LPH "high pressure" fuel pump can support 390HP. Bosch 044s are inline fuel pumps. Although they may be installed in-tank, some custom fabrication will usually be required. Bosch turbine fuel pumps offer many advantages when compared to older roller-cell and inner-gear pump designs. Not only do these pumps offer near-silent operation and improved drivability, the core components of the turbine design significantly reduce wear and deliver a longer service life. That's an important consideration when choosing a performance fuel pump. Application-specific, illustrated step-by-step instructions are included.


300LPH free flow and 200LPH at 5 bar (72.5 psi) for up to 685HP on gasoline or ~550hp on E85
Fully compatible with gasoline, E85, RE85 and diesel fuel
Near silent operation
Improved drivability
Replacement for Bosch fuel pump 0580254044
Max flow >220 - 270 l/h @ 5 Bar / 13 V (gasoline)
Up to 7 Bar pressure
Input M18X1.5 inner thread, internal 130 micron filter (not changeable)
Input without adapter: M14X1.5 inner thread
Pressure side M12X1.5, outer thread with check valve
Body diameter 60 mm, 52 mm without plastic fitting
Electrical connectors: - M5 / + M4
Current consumption 17 A @ 5 bar / 13 V, +22 °C
Internal overpressure valve 8 - 10 Bar

WARNING: Cancer and Reproductive Harm -

Type: Fuel Pumps*
